Model | 2JK-3T | 2JK-5T |
Fixed force of traction(KN) | 30 | 50 |
Steel wire rated speed (m/min) | 30 | 28.5 |
Steel cable diameter (mm) | 17 | 21.5 |
Reduction gear model | JZQ500 | JZQ650 |
Overall ratio | 23.34 | 40.17 |
Reel diameter (mm) | 270 | 400 |
Reel width (mm) | 500 | 840 |
Rope Chute (m) | 200 | 240 |
Electrical machinery model | JZR225-8 | YZR250-8 |
Electrical machinery power (KW) | 22 | 30 |
Electrical machinery rotational speed(R/M) | 720 | 720 |
Hydraulic Brake | YWZ-300 | YWZ-300 |
Machine weight (kg) | 2000 | 3500 |
External dimensions (mm) | 1900×1400×950 | 3300×1600×1000 |
